Bigstorage BOX, rozšíření +15kWh
High-performance energy storage system.
A compact and modular energy storage system utilizing lithium iron phosphate batteries. The system features a powerful DC distribution board, a Victron CerboGX control unit, and an advanced battery management system. Ideal for connection to photovoltaic systems and Victron Multiplus inverters.
| Category: | Energy storage systems |
|---|
- DC distribution board including fuses 160 or 125A (individual inverters or MPPT can be connected)
- CerboGX - Victron control unit. Every Victron installation includes this unit. Thanks to our battery, it's already connected and ready for use.
- Switch - STOP button
- Battery Management - FishBMS - battery management master module + 2 measuring modules + disconnector including relay + current sensor (Specific component from Evracing, functionality verified by more than 10 years of operation.)
- Ideal for connecting units up to Victron Multiplus II 8000VA power, MPPT 250/100
Technical Parameters:
- 16 or 32 pcs lifepo4 cells, manufacturer EVE quality A+ capacity 304Ah, voltage 3.2V
- 16pcs ⇒ 16*3.2*304 = 15.56kWh ⇒ we say 15kWh etc.
- Max discharge current recommended 0.5C, peak 1C, ideally up to 0.3C
