Bigstorage BOX
High-Performance Energy Storage System
A compact and modular energy storage system utilizing lithium iron phosphate batteries. 1 The system is equipped with a powerful DC distribution board, a Victron CerboGX control unit, and an advanced battery management system. Ideal for connection to photovoltaic systems and Victron Multiplus inverters.
| Category: | Energy storage systems |
|---|
- DC distribution board incl. fuses 160 or 125A (individual inverters or MPPTs can be connected)
- CerboGX - Victron control unit. Every Victron installation includes this unit. Thanks to our battery, it is already connected and ready for use
- Switch - STOP button
- Battery Management - FishBMS - battery management master module + measuring module 2pcs + disconnector incl. relay + current sensor (functionality verified by more than 10 years of operation.)
- Ideal for connecting three Victron Multiplus II 8000VA units (i.e., battery power up to 24kVA), max 3pcs MPPT 250/100
Technical parameters:
- 32pcs lifepo4 cells, manufacturer EVE quality A+ capacity 304Ah, voltage 3.2V
- Nominal capacity 31.12kWh
- Maximum discharge current recommended 0.5C, peak 1C, ideally up to 0.3C (i.e., 10kW continuous)
- Weight 170kg
- Can be screwed to the wall or placed on the floor
- Expandable in multiples of 15kWh up to a maximum capacity of 240kWh (Bigstorage BOX system)
